Wireless & Network Interface Specifications

Dual-Band Wi-Fi 6 (802.11ax)

Transmission Standard: IEEE 802.11ax/n/g/b on 2.4 GHz & 802.11ax/ac/n/a on 5 GHz.

MIMO Configuration: 2 x 2 MIMO on both frequency bands for increased speed and reliability.

• 2.4 GHz Band: Up to 574 Mbps.

• 5 GHz Band: Up to 2402 Mbps.

• Total Combined Rate: Up to 2976 Mbps.

• Frequency Band: Simultaneous 2.4 GHz & 5 GHz. Supports 5 GHz priority for faster, less congested connections.

• Antenna: Internal antennas.

• Network & Connectivity

• Auto-Adaptive Ethernet Ports: Features three 10/100/1000 Mbps Gigabit ports. Any port can automatically function as a WAN (for Internet input) or LAN (for wired device connection), simplifying setup.

• Buttons & Indicators

• H (Hi) Button: A multi-function button for one-touch WPS connection and seamless pairing with HarmonyOS smart devices.

• Reset Button: Independent pinhole button for restoring factory defaults.

• LED Indicator: A single "H" indicator with red/blue status lights for visual feedback on operation mode and connection status.

• Power

• Power Supply: Standard DC power port for the included adapter.
